SOLVED: Exchange Online Management PowerShell Connect-ExchangeOnline bug "A window handle must be configured. See https://aka.ms/msal-net-wam#parent-window-handles"

While you're here why not check out our Exchange audit and documentation tool?

If you're using the Exchange Online Management PowerShell cmdlets you may notice that the following error:

A window handle must be configured. See https://aka.ms/msal-net-wam#parent-window-handles

This error appears in version 3.7.0 (and persists in version 3.7.1) when the following change was made.

Integrated WAM (Web Account Manager) in Authentication flows to enhance security.

You notice that this error occurs in PowerShell ISE but not in a PowerShell, the issue also appears in any Windows based applications - for example a WinForms application that tries to execute Connect-ExchangeOnline

PowerShell ISE

A .NET console application does work correctly.

.NET console application

While you're here why not check out our Exchange audit and documentation tool?

The error occurs because Microsoft has made the (correct) decision that when an interactive login prompt it must have a parent window so that the dialog doesn't appear behind another window thereby not visible to the user. This is implemented by the MSAL library.

However the code they used to determine the parent window can be seen below.

/// <summary>
/// Initializes the Public Client Application or extract from map
/// if already present. Also it enters the instance in the map if newly created.
/// </summary>
/// <returns>An instance of PCA from the map or intializes and returns it</returns>
private IPublicClientApplication GetPublicClientInstance()
{
    IPublicClientApplication publicClientApplication;
    if (!MSALTokenProvider.publicClientApplicationMap.TryGetValue(this.context.AzureADAuthorizationEndpointUri, out publicClientApplication))
    {
        BrokerOptions brokerOption = new BrokerOptions(BrokerOptions.OperatingSystems.Windows);
        publicClientApplication = (!RuntimeInformation.IsOSPlatform(OSPlatform.Windows) ? PublicClientApplicationBuilder.Create(this.context.ClientAppId).WithAuthority(this.context.AzureADAuthorizationEndpointUri, true).WithRedirectUri(this.context.ClientAppRedirectUri.ToString()).WithClientCapabilities(new string[] { "cp1" }).Build() : PublicClientApplicationBuilder.Create(this.context.ClientAppId).WithAuthority(this.context.AzureADAuthorizationEndpointUri, true).WithRedirectUri(this.context.ClientAppRedirectUri.ToString()).WithClientCapabilities(new string[] { "cp1" }).WithParentActivityOrWindow(new Func<IntPtr>(ParentWindowHandle.GetConsoleOrTerminalWindow)).WithBroker(brokerOption).Build());MSALTokenProvider.publicClientApplicationMap.TryAdd(this.context.AzureADAuthorizationEndpointUri, publicClientApplication);
    }
    return publicClientApplication;
}

As seen in the code above this uses the GetConsoleWindow low level API to determine the handle of the parent console window.
https://learn.microsoft.com/windows/console/getconsolewindow

"We do not recommend using this content in new products"

They are using dated methods that they don't recommend themselves, but more importantly they are looking for a console window and therefore if you're not running a console app then there's no handle returned from the method.

The issue persists in ExchangeOnlineManagement version 3.7.1 so it's a concern that Microsoft are not going to fix this issue.

Workaround 1: Downgrade

In the mean time you can uninstall the latest versions and roll-back to version 3.6.0 which didn't have the issue.

Uninstall-Module -Name ExchangeOnlineManagement -AllVersions -Force
Install-Module -Name ExchangeOnlineManagement -RequiredVersion 3.6.0 -Force

Workaround 2: Open a console window

You can also open a console window in PowerShell ISE or your windows application, this is not great as it opens a console window in the background.

$consoleSupportSource = @’
using System;
using System.Runtime.InteropServices;
public class ConsoleSupportMethods
{
   [DllImport("kernel32.dll", SetLastError = true)]
   public static extern int AllocConsole();

   [DllImport("kernel32.dll", SetLastError = true)]
   public static extern int FreeConsole();
}
‘@

Add-Type -TypeDefinition $consoleSupportSource
try
{
   [ConsoleSupportMethods]::AllocConsole();
   Connect-ExchangeOnline;
}
catch
{
   throw;
}
finally
{
   [ConsoleSupportMethods]::FreeConsole();
}



Workaround 3: Handle MSAL Authentication yourself

The best solution is to handle the MSAL authentication yourself and then pass an access token to Connect-ExchangeOnline. The Exchange team are constantly shunning standards (the whole backend of these cmdlets are a botched REST API that passes the cmdlet name) so you're really stuck with the cmdlets but you can at least rid yourself of their authentication code.

The following sample code uses the MSAL libraries that are installed as part of the Exchange PowerShell cmdlets so you don't need to install these separately.

$msalPath = [System.IO.Path]::GetDirectoryName((Get-Module ExchangeOnlineManagement).Path);
Add-Type -Path "$msalPath\Microsoft.IdentityModel.Abstractions.dll";
Add-Type -Path "$msalPath\Microsoft.Identity.Client.dll";
[Microsoft.Identity.Client.IPublicClientApplication] $application = [Microsoft.Identity.Client.PublicClientApplicationBuilder]::Create("fb78d390-0c51-40cd-8e17-fdbfab77341b").WithDefaultRedirectUri().Build();
$result = $application.AcquireTokenInteractive([string[]]"https://outlook.office365.com/.default").ExecuteAsync().Result;
Connect-ExchangeOnline -AccessToken $result.AccessToken -UserPrincipalName $result.Account.Username;
